LD5100C


 LD5100C   - 4.5" (114MM) WIDE ELECTRIC LABEL DISPENSER "HIGH SPEED"

Designed to see CLEAR LABELS
Ideal for virtually any kind of label; from bar code to packaging
Will dispense labels and die-cut parts
Will dispense labels from .25" to 4.5" (6.4 to 114mm) in width
Will dispense labels from .50" to 6" (12.7 to 152mm) in length
Will accommodate core sizes from 1" (25.4 mm) up
Photo sensor accuracy
Automatically removes paper, vinyl, acetate, polyester, foil, etc. from its liner
Automatically rewinds liner scrap for a cleaner working environment
Liner scrap is easily removed
No tools required for adjusting to different size labels
All metal construction
No maintenance required
Adjustable strip plate for hard-to-release labels

Model # Liner Capacity Width Length Roll Capacity Feed Speed* Dimensions Electrical Requirements Weight
LD5100C .25" to 4.5" (6.35mm to 114.3mm) .50" to 6" (12.7mm to 152mm) 12" (30.5cm) 3.3"/sec (8cm/sec) 10.8"(L)x10.8"(W)x14.5"(H) 27.4cm(L)x27.4cm(W)x36.8cm(H) 100/120V 50/60Hz, <1 amp (220V 50/60Hz available) 10.5 lbs (4.76 kg)
  * speed calculated at 60Hz
